The RF Micro C8X Series RF coaxial connector data sheet details specifications, applications, ordering information, and production capacity.
The C8X Series RF coaxial connector from RF Micro is a board‑mount receptacle and plug assembly designed for high‑frequency transmission between RF modules and antennas in devices such as notebooks, PDAs, mobile phones, GPS and Bluetooth. It complies with RoHS, HF and PFOS standards and is compatible with mainstream connectors.
The data sheet lists key specifications including operation up to 6 GHz, cable retention forces of 10 N (0.81 contact) and 20 N (1.13 contact), and precise receptacle dimensions (e.g., 2.0 × 2.0 × 0.85 mm). Ordering part numbers for plugs and receptacles are provided, along with mass‑production capabilities and quality‑control measures such as 100 % CCD inspection.
| Maximum operating frequency | 6 GHz |
|---|---|
| Cable retention force (0.81 contact) | 10 N min |
| Cable retention force (1.13 contact) | 20 N min |
| Receptacle dimensions (example) | 2.0 × 2.0 × 0.85 mm |
| Electrical discontinuity tolerance | ≤ 1 µs after 10 pulls at 10 N |
The connector can operate up to 6 GHz.
A minimum retention force of 10 N is required.
The receptacle measures 2.0 × 2.0 × 0.85 mm.
