Technical data sheet for REMBE C-LEVER bulk‑solids gravimetric weighers and UNIBAND stainless‑steel belt scales.
The C-LEVER series provides gravimetric weighing of bulk solids with a compact, low‑height design and friction‑compensated accuracy of up to ±0.5 %. It is available in stainless‑steel versions for sanitary environments and can be installed without specialist assistance. UNIBAND is a maintenance‑free stainless‑steel belt scale that fits under existing conveyor belts. It offers high accuracy, optional belt‑speed tachometer, and can be used in potentially explosive zones. Both products are CE‑certified and meet ATEX, FM‑Global and other international safety standards.
| Accuracy | ± 0.5 to 2 % |
|---|---|
| Operating temperature | −40 °C to +75 °C (optional up to +160 °C) |
| Supply voltage | 5 V to 12 V DC |
| Output signal | 0 mV to 20 mV |
| Material (C‑LEVER standard) | Carbon steel St52, powder‑coated |
| Material (UNIBAND standard) | Stainless steel 1.4301 (AISI 304) |
| Overload protection | Safe up to 150 % of nominal capacity (max 300 %) |
The C‑LEVER mini can measure flows as low as 0.3 m³/h.
Yes, UNIBAND is suitable for use in potentially explosive zones.
