This manual explains how to set up a Raspberry Pi, configure the OS, enable VNC, and connect e‑paper display modules.
The guide provides a step‑by‑step overview of the Raspberry Pi hardware, required accessories, and initial configuration procedures, including formatting the MicroSD card, installing the operating system image, and completing the first‑boot setup. It also covers enabling remote access via VNC and SSH.
Further sections describe how to connect the Raspberry Pi to DESPI‑C03 or DESPI‑C1248 e‑paper driver boards, install the bcm2835 library, and run the e‑paper driver software. Common Raspberry Pi commands and troubleshooting tips are included at the end. This manual is written in Chinese.
| MicroSD card size | At least 8 GB |
|---|---|
| Power supply | 5 V 2 A adapter |
| Display interface | HDMI compatible monitor |
| GPIO interfaces | Custom GPIO, USB, Ethernet |
Use a card reader and the SDFormatter tool to format the MicroSD card before writing the OS image.
Open the Raspberry Pi Configuration menu, go to the Interfaces tab, set VNC to "Enable", click OK and reboot.
