The Philips SD700 user manual provides setup, operation, Bluetooth pairing, FM radio, and troubleshooting instructions for the wireless portable speaker.
This manual introduces the Philips SD700 wireless portable speaker, describing its features such as FM radio, Bluetooth, Micro SD/USB playback, and headphone use. It lists the items included in the box and explains the basic controls for power, source selection, and volume.
Detailed sections cover how to charge the built‑in battery, pair and connect Bluetooth devices, play audio from various sources, adjust settings, and resolve common issues. Safety warnings and environmental disposal guidelines are also provided. This manual is written in Chinese.
| Output Power | 2 × 1.5 W RMS |
|---|---|
| Frequency Response | 60 – 20000 Hz ±3 dB |
| Signal‑to‑Noise Ratio (SNR) | > 70 dB(A) |
| Aux Input | 600 mV RMS, 22 kΩ |
| FM Tuning Range | 87.5 – 108 MHz |
| Bluetooth Version | V3.0+EDR |
| Bluetooth Range | ≈ 10 m (30 ft) |
| Speaker Impedance | 4 Ω |
| Speaker Sensitivity | > 79 ± 3 dB/m/W |
| Power Input (USB) | 5 V 500 mA |
| Battery Capacity | 3.7 V 850 mAh |
| Standby Power Consumption | < 0.5 W |
| Dimensions (W×H×D) | 164 × 63 × 33 mm |
| Weight | 0.35 kg |
Press and hold the PAIRING button until a beep sounds, then select "Philips SD700" on the device and, if prompted, enter the default PIN "0000".
The Bluetooth connection works up to about 10 meters (30 feet) in open space.
Standby power consumption is less than 0.5 W.
