The manual details the MM5000 Tornado series ultra‑HD video wall processor, its hardware architecture, input/output cards, specifications and connection…
The MM5000 Tornado series ultra‑HD video wall processor from MviewTech is a high‑performance, hardware‑only video image processing system designed for education, research, government, security monitoring and commercial display applications. It integrates multi‑channel HD/8K video capture, real‑time high‑resolution processing and advanced image transformation functions.
The system uses a pure FPGA hardware architecture with no embedded operating system, offering flexible input card combinations (DVI‑M, HDMI, DisplayPort, VGA, SDI, HDBaseT, etc.) and a variety of output cards supporting up to 160 synchronized channels. Network (RJ‑45) and RS‑232 interfaces enable remote control and integration with matrix switches or projectors, while optional touch‑screen panels provide visual operation. This manual is written in Chinese.
| Maximum Input Resolution | 8K×4K |
|---|---|
| Maximum Output Channels | 160 |
| Working Voltage | AC 100 V‑240 V, 50/60 Hz |
| Operating Temperature | 0‑50 °C |
| Maximum Input Card Count per 1.5U | 3 cards |
| Network Interface | RJ‑45 10/100 M auto‑negotiation |
It supports a wide range of input interfaces including DVI‑M, HDMI, DisplayPort, VGA, DVI, Dual‑Link DVI, SDI, CVBS, HDBaseT, YPbPr/YCbCr, IP and fiber.
The MM5000 can provide up to 160 synchronized output channels.
Yes, it includes a RJ‑45 Ethernet port with 10/100 M auto‑negotiation and an open API for network control.
