The MPC03LX motion control card wiring manual provides connection diagrams and usage notes for two‑axis stepper control, laser power, limit and home switches.
This manual describes the wiring method for the MPC03LX motion control card, including the overall connection overview and detailed diagrams for each signal type. It covers a two‑axis stepper control system example, the controller‑to‑laser power connection, and the wiring of home and limit switches.
Additional sections list the pin definitions for the X62 connector, give precautions for power connections, and provide a change‑record table. The document is intended for engineers integrating the card into laser cutting or motion control equipment. This manual is written in Chinese.
| Supply current (example power supply) | 10 A |
|---|---|
| Number of I/O pins (X62 connector) | 62 |
| Home switch active level | Low level |
| Limit switch active level | High level |
| Laser power control pin | Pin 48 (low‑level active) |
The laser power control signal is connected to pin 48, which is low‑level active.
The home switch operates with a low‑level active signal.
The limit switch uses a high‑level active signal.
