MIKOM MX2H-CAN-BD Communication Expansion Module Hardware Manual

This hardware manual covers the electrical specifications, installation wiring, maintenance, and software settings for the MIKOM MX2H-CAN-BD communication…

Brand: MIKOM
Category: Industrial Robot
Document type: User Manual
Language: Chinese
Pages: 2
File format: PDF
File size: 1.1 MB
Published: 17 October, 2026
Updated: 17 October, 2026
MD5 checksum: B0B3A45D6774E113C492737213BFCA01
PDF: MIKOM MX2H-CAN-BD Communication Expansion Module Hardware Manual PDF

About this manual

The document provides a comprehensive guide for the MIKOM MX2H-CAN-BD communication expansion card designed for MX2H series PLC main modules. It details the physical structure, port definitions, power consumption specifications (15mA max at 24V/GND), and supported protocols including free port protocol and MXLink. This manual is written in Chinese.

What's inside

Product Introduction
Installation Instructions
Pin Definition
Communication Specifications
CAN Network Wiring
Electromagnetic Interference Prevention
Software Configuration

Specifications

Signal Standard	CAN
Max Transmission Distance	10km (dependent on baud rate)
Communication Mode	Half-duplex
Supported Protocols	Free port protocol, MXLink (Master/Slave)
Operating Power Supply	3.3VDC

Frequently asked questions

What is the maximum transmission distance for the MX2H-CAN-BD?

The maximum transmission distance depends on the baud rate, reaching up to 10 kilometers.

Which communication protocols does this module support?

The CAN port supports free port protocol and MXLink communication protocol (Master/Slave).
