Featured MIKOM manuals
Mikom MX2H Series PLC Application in Multicolor Printing Machine Application Note
The document presents a solution that uses Mikom MX2H series PLCs with CAN bus communication to manage a multicolor printing machine. The main station uses an MX2H‑3232M‑CAN PLC for logic control and touchscreen communication, while MX1H‑1616‑CAN PLCs serve as remote I/O stations.
Key features include extensive expansion modules, multiple communication interfaces (RS‑232, RS‑485, CAN), fast instruction processing, Ethernet remote maintenance, and specialized high‑speed commands for precise ink and water control, plate adjustment, and system responsiveness. This manual is written in Chinese.
Covers: Abstract · Product Introduction · System Architecture and Hardware Configuration · Function Details and Program Design · CAN Network Setup · Inverter Communication
Latest MIKOM manuals
Mikom MX2H Series PLC Application in Multicolor Printing Machine Application Note
Application Note 6 pages · 846 KB · ZHThis application note describes how the Mikom MX2H series PLC is used to control a multicolor printing machine via CAN bus, covering system architecture…
Which document do I need?
Application Note
How to use the product for one specific task, with worked examples.
Questions answered in MIKOM manuals
What communication interfaces does the MX2H series PLC provide?
It includes two RS‑232 ports, one RS‑485 port, and one CAN interface.
From: Mikom MX2H Series PLC Application in Multicolor Printing Machine Application Note
How many I/O points are available in the system?
The system has a total of 218 I/O points, with 94 inputs and 124 outputs.
From: Mikom MX2H Series PLC Application in Multicolor Printing Machine Application Note
