This datasheet covers the dsPIC33FJ32MC202/204 and dsPIC33FJ16MC304 high-performance 16-bit digital signal controllers, detailing specifications…
This document is a datasheet for the dsPIC33FJ32MC202/204 and dsPIC33FJ16MC304 high-performance 16-bit digital signal controllers (DSCs). It provides a comprehensive overview of the product series, including device features, CPU architecture, memory configuration, and various peripherals such as timers, ADCs, and communication modules.
The datasheet details the electrical characteristics, operating conditions, and pin configurations for the available packages, including 28-pin SDIP/SOIC/QFN-S and 44-pin QFN/TQFP. It also lists specific device variations within the series, highlighting differences in flash memory size, RAM, and the number of available I/O pins. This manual is written in Chinese.
| Operating Speed | Up to 40 MIPS |
|---|---|
| Operating Voltage | 3.0-3.6V |
| Temperature Range (Industrial) | -40°C to +85°C |
| Temperature Range (Extended) | -40°C to +125°C |
| Flash Program Memory (dsPIC33FJ32MC202/204) | 32 KB |
| Data SRAM | 2 KB |
| ADC Resolution | 10-bit or 12-bit |
| ADC Sampling Rate (10-bit) | 1.1 Msps |
| ADC Sampling Rate (12-bit) | 500 Ksps |
| PWM Channels (Motor Control) | 6 channels |
| I/O Pins (dsPIC33FJ32MC202) | 21 pins |
The maximum operating speed is up to 40 MIPS at 3.0-3.6V.
The devices support industrial grade (-40°C to +85°C) and extended grade (-40°C to +125°C) temperature ranges.
The maximum flash program memory size is 32 KB.
The devices support 10-bit conversion at 1.1 Msps or 12-bit conversion at 500 Ksps.
