Mean Well DRA-60 Series 60W Single Output Power Supply Datasheet

This datasheet covers the Mean Well DRA-60 series, a 60W DIN-rail power supply with adjustable output current via resistor, voltage, or PWM signal.

Brand: Mean Well
Category: Power Management
Document type: Datasheet
Language: Chinese
Pages: 5
File format: PDF
File size: 918 KB
Published: 14 October, 2026
Updated: 14 October, 2026
MD5 checksum: 97EF14A9E2F8AF959C363E53E652E136
PDF: Mean Well DRA-60 Series 60W Single Output Power Supply Datasheet PDF

About this manual

The Mean Well DRA-60 Series is a 60W single-output AC/DC power supply designed to meet German industrial standards (TS35/7.5 or TS35/15). It features full-range universal AC input from 90VAC to 264VAC and operates in natural convection cooling without requiring a fan. This manual is written in Chinese.

What's inside

Electrical Specifications
Current Adjustment Methods
Protection Features
Environmental Conditions
Mechanical Dimensions
Application Areas

Specifications

Input Voltage Range	90 ~ 264VAC

Frequently asked questions

What is the operating temperature range for the DRA-60 Series power supply?

The unit can operate in temperatures ranging from -30°C to +70°C.

What are the recommended installation distances when the unit is permanently loaded at full power?

The recommended distances are 40mm at the top, 20mm at the bottom, and 5mm on each side.

Download PDF (918 KB)
