Mean Well RID-85A Switching Power Supply Datasheet

The Mean Well RID-85A datasheet provides specifications for an 85 W isolated switching power supply with dual outputs.

Mean Well RID-85A Switching Power Supply Datasheet - cover page
Brand
高性能85W内置有外壳隔离型双组输出明纬开关电源
Category
Automation control Equipment
Document type
Datasheet
Language
Chinese
Pages
1
File format
PDF
File size
359 KB
Published
03 December, 2011
Updated
08 October, 2026
MD5 checksum
8C4FAAAA65F2F1F23B46A924611E5236
PDF
Mean Well RID-85A Switching Power Supply Datasheet PDF

About this manual

The RID-85A is an 85 W isolated switching power supply designed for industrial applications. It supports a wide input voltage range and offers selectable output voltages of 5 V, 12 V, and 24 V with high efficiency.

The module complies with multiple safety and EMC standards, including UL, EN5500‑1, EN61000‑3‑2, and EN61000‑4‑2. It operates from –20 °C to +70 °C and is compact, measuring 159 × 97 × 38 mm. This manual is written in Chinese.

What's inside

  • General Description
  • Electrical Specifications
  • Mechanical Dimensions
  • Protection Features
  • Certifications and Standards

Specifications

Input Voltage Range264 VAC
Output Voltage Options5 V, 12 V, 24 V
Dimensions159 × 97 × 38 mm

Frequently asked questions

What is the input voltage range of the RID-85A?

The input voltage range is 264 VAC.

What output voltages are available?

The power supply can provide 5 V, 12 V, or 24 V outputs.

Download PDF (359 KB)
