MagnTek PB006 Encoder IC Programming Tool User Manual

About this manual

The PB006 programming tool and its GUI software are used to program MT6501 series magnetic encoder ICs, including MT6501CT and MT6501GT. The manual provides detailed installation steps for drivers and software, as well as instructions for three programming modes: single‑part single‑source, dual‑part dual‑source, and dual‑part single‑source.

The guide also covers the software interface, parameter settings, switch‑output programming, and safety precautions. It includes information on the supplied accessories such as a 5 V power adapter, USB cable, and a USB flash drive containing drivers and software.

What's inside

• Overview
• Programmer and Accessories
• Software Installation
• Software Operation
• About Interface
• Precautions

Specifications

Frequently asked questions

How do I install the driver for the PB006 programmer?

Open the "Drive" folder on the supplied USB drive, unzip and install the "CH341SER.rar" driver.

Can I create a desktop shortcut during software installation?

Yes, the installer asks whether to create a shortcut on the desktop; the default is to create it.
