The Laurel X7 Series Currency Sorter leaflet describes its features, specifications, and options for efficient banknote sorting.
The X7 Series is a compact 1 + 1 pocket currency sorter with enhanced counterfeit detection, multiple sorting modes (Denomination, Face, Orientation, Issue, Count), and a full‑graphic LCD for easy operation. It includes IR, MG, UV sensors for reliable authentication and a status indicator that alerts operators to stacker, note, or error conditions.
Technical specifications include dimensions of 280 × 290 × 310 mm, weight of about 12.5 kg, sorting speed up to 900 notes per minute, hopper capacity of 500 notes, and power consumption of 70 W while counting (15 W at rest). The machine supports up to five currencies and offers RS‑232C, printer, and customer‑display interfaces.
| Dimensions (H × W × D) | 280 × 290 × 310 mm |
|---|---|
| Weight | Approx. 12.5 kg |
| Sorting Speed | Up to 900 notes/min |
| Hopper Capacity | Max. 500 notes |
| Stacker Capacity | Max. 250 notes |
| Reject Capacity | Max. 100 notes |
| Display | Full Graphic LCD (240 × 128 dots) |
| CF Detection | IR, MG, UV |
| Multi‑Currency Function | Max. 5 currencies (option) |
| Interface | RS‑232C, Printer, Customer Display OSD‑1 |
| Power Source | 100‑125 V / 200‑240 V, 50/60 Hz |
| Power Consumption | 70 W (counting), 15 W (rest) |
It supports Denomination, Face, Orientation, Issue, and Count sorting modes.
Up to five currencies can be programmed for the X7 Series.
The machine can sort up to 900 notes per minute.
It uses 70 W while counting and 15 W when idle.
