Selection guide for KORAI inductive, photoelectric, capacitive and ultrasonic sensors with technical parameters and application notes.
The KORAI Sensor Selection Manual provides an overview of the company's sensor portfolio, including inductive, photoelectric, capacitive, ultrasonic and explosion‑proof sensors. It describes the basic operating principles, typical applications and the range of product families available.
Technical data sheets for each sensor type are included, covering housing material, connection method, protection class, installation style, switching frequency, supply voltage, temperature range, voltage drop, output current, LED indication and compliance certifications. The manual also explains selection rules, Teach‑in self‑learning adjustment and wiring recommendations. This manual is written in Chinese.
| Supply Voltage | 10…30 VDC (≤20 % ripple) |
|---|---|
| Housing Material | Stainless steel V2A |
Inductive sensors can operate up to 3,000 Hz.
Yes, the sensors include built‑in short‑circuit and overload protection.
