2013 Kemppi product catalogue featuring the MinarcMig Evo 170/200 MIG/MAG welding equipment and its specifications.
The Kemppi product catalogue 2013 presents the company's global welding solutions, highlighting its presence in over 70 countries and a range of MIG/MAG, TIG, MMA and automation products. The catalogue emphasizes energy‑efficient inverter technology and the company's commitment to quality and customer support.
The MinarcMig Evo 170/200 series is a compact, portable MIG/MAG welding system offering 170 A or 200 A output at a 35 % duty cycle from a 16 A single‑phase supply. It features an adaptive arc regulation system, automatic or manual mode selection, a large graphical interface, and the ability to operate with long power cables over 100 m. Technical data such as dimensions, weight, voltage range and warranty details are provided.
| Welding current (model) | 170 A / 200 A |
|---|---|
| Duty cycle | 35 % at 16 A supply |
| Power factor (max current) | 0.99 |
| External dimensions (L × W × H) | 450 mm × 227 mm × 368 mm |
| Supply voltage | 230 V ± 15 % (1‑phase) |
| Wire feed speed adjustment range | 1 … 12 m/min (170 A) / 1 … 13 m/min (200 A) |
| Efficiency at 100 % ED | 80 % (170 A) / 82 % (200 A) |
Both models deliver a 35 % duty cycle when powered from a 16 A single‑phase mains supply.
The system reaches a power factor of 0.99 at its maximum current.
