Hybrid Vehicle User Manual for CSA7144CDPHEV Series

This manual covers vehicle identification, instrument cluster usage, lighting controls, seat adjustments, safety systems (airbags/child seats), driving…

Hybrid Vehicle User Manual for CSA7144CDPHEV Series - cover page
Document type
User Manual
Language
Chinese
Pages
299
File format
PDF
File size
51.4 MB
Published
17 October, 2026
Updated
17 October, 2026
MD5 checksum
BCAC8510DD7BC5AC3CA008E53BE39263
PDF
Hybrid Vehicle User Manual for CSA7144CDPHEV Series PDF

About this manual

This user manual provides comprehensive operating instructions for a hybrid vehicle. It details the use of instruments and control devices, including the combination meter, warning lights, and various switches for lighting, wipers, mirrors, windows, and climate control systems.

The document also covers safety features such as seatbelts, airbags, and child protection locks, along with specific procedures for starting the vehicle (key or keyless), driving modes, energy recovery, and charging requirements. Technical data tables are included at the end regarding motor specifications, fluid capacities, and wheel alignment parameters. This manual is written in Chinese.

What's inside

  • Vehicle Identification
  • Instrument Cluster
  • Lighting and Switches
  • Seats and Safety Belts
  • Airbags
  • Child Protection Devices
  • Starting and Driving
  • Eco-Driving
  • Fuel System
  • Charging Requirements

Specifications

Hybrid Motor Max Speed7000 rpm
Motor Controller Input Voltage230 ~ 393 V
Engine Oil Capacity (Initial)4.5 L
Coolant Type (Battery Pack)Ethylene Glycol Type (OAT)
Recommended Tire Size225/55 R17

Frequently asked questions

What are the recommended tire specifications?

The recommended wheel rim size is 7.0J x 17 and the tire specification is 225/55 R17.

What type of coolant is required for the high-voltage battery pack?

The high-voltage battery pack requires Ethylene Glycol Type (OAT) coolant.
