The Heijin Power AV6045 user manual describes the FPGA video processing development platform, its interfaces, specifications, and operation instructions.
The AV6045 is a professional‑grade Xilinx FPGA video processing development platform that provides four composite video inputs, HDMI input and output, VGA output, Gigabit Ethernet, and a CMOS camera interface. It is built around a Xilinx Spartan‑6 XC6SLX45‑2FG484 FPGA with DDR3 memory and multiple peripheral interfaces, targeting video processing, storage, and communication applications.
The manual covers an introduction to the system, detailed functional descriptions, the FPGA core board layout, extension board modules, pin assignments, JTAG programming, button functions, and power supply requirements. It also includes schematics, connector pin tables, and hardware specifications to aid developers in using and extending the platform. This manual is written in Chinese.
| FPGA Chip | Xilinx Spartan‑6 XC6SLX45‑2FG484 |
|---|---|
| DDR3 Capacity | 2 Gbit |
| Memory Bandwidth | 10 Gb/s (666 M × 16 bit) |
| Video Input Channels | 4 composite (TW2867) + HDMI + CMOS camera |
| Ethernet PHY | Realtek RTL8211E (10/100/1000 Mbps) |
| Power Input Voltage | DC 5 V |
It uses a Xilinx Spartan‑6 XC6SLX45‑2FG484 FPGA.
The board supports four composite video inputs via TW2867, plus HDMI and a CMOS camera interface.
The board requires a DC 5 V input, which is regulated internally to 3.3 V, 1.2 V and 1.8 V rails.
Yes, it includes a Realtek RTL8211E PHY that supports 10/100/1000 Mbps Ethernet.
