Hanbell AE3 series air compressor operation manual with safety guidelines, installation steps, system overview, and maintenance procedures.
This manual provides comprehensive safety precautions, inspection, handling, and installation instructions for the Hanbell AE3 screw air compressor. It details environmental requirements, wiring guidelines, and control system setup to ensure safe and reliable operation.
The document also describes the system components, micro‑controller functions, routine maintenance, and troubleshooting. Technical specifications such as operating temperature range, input voltage, and power ratings are listed for reference. This manual is written in Chinese.
| Operating temperature range | 0 °C ~ 45 °C |
|---|---|
| Input voltage | 380 V, 50/60 Hz |
| Maximum discharge pressure | see nameplate (specified on the unit) |
Read the manual thoroughly, ensure proper grounding, use a dedicated NFB switch, and verify that all safety signs are observed before powering the unit.
Check the nameplate on the compressor or motor and make sure the circuit voltage matches the specified value.
Turn off the power, release pressure from the oil‑gas separator, open the oil tank and cooler drain valves, completely drain the old oil, then refill with the specified Hanbell oil and verify the oil level.
