The HTPXI2010I is a single‑channel signal‑conditioning module with full isolation, ±22 Vrms/2 A output and 1000 V isolation, suitable for PXI test systems.
The HTPXI2010I single‑channel signal‑conditioning module offers full input, output and power isolation up to 1000 V, and delivers high‑power ±22 Vrms, 2 A signals. It occupies three PXI 3U slots and is powered from standard PXI supplies with an external 220 VAC source.
Technical specifications include a DC‑coupled input range of 0‑±5 Vrms, bandwidth over 10 kHz, gain of 4.4, and compliance with EMC and safety standards. The module operates from 0 °C to 50 °C, weighs about 0.7 kg, and is supported by Haitai’s service network. This manual is written in Chinese.
| Coupling Type | DC |
|---|---|
| Input Signal Range | 0 ~ ±5 Vrms |
| Output Voltage Range | 0 ~ ±22 Vrms |
| Output Current | ≥ 2 A |
| Isolation Voltage | > 1000 V |
| Bandwidth | > 10 kHz |
| Power Supply | 220 VAC/200 W; 12 VDC/2 W |
| Weight | ≈ 0.7 kg |
| Operating Temperature | 0 °C ~ 50 °C |
| Storage Temperature | -40 °C ~ +70 °C |
The module offers full isolation with a voltage rating of greater than 1000 V.
It requires a 220 VAC supply (200 W) and an auxiliary 12 VDC supply (2 W).
