The HTPCI‑GPIB conversion card from HaiTai provides PCI‑to‑GPIB protocol conversion, supporting up to 14 instruments with >1 MB/s data rate.
The HTPCI‑GPIB conversion card enables a host PC to control GPIB instruments via a PCI interface. It offers a graphical bus configuration interface and complies with IEEE‑488.2, allowing seamless integration with NI VISA and Keysight VISA drivers.
Technical specifications include support for up to 14 GPIB devices, a data transfer rate exceeding 1 MB/s, PCI 3.0 compatibility, a standard 24‑pin IEEE‑488 female connector, and dimensions of 135.7 mm × 121 mm × 21.6 mm. The card draws 5 V ± 5 % from the host PC and operates in temperatures from 0 °C to 50 °C. This manual is written in Chinese.
| Maximum GPIB instruments | 14 |
|---|---|
| Data transfer rate | >1 MB/s |
| Supported standards | PCI3.0, IEEE‑488.1, IEEE‑488.2 |
| Connector type | Standard 24‑pin IEEE‑488 female |
| Software compatibility | NI VISA, Keysight VISA |
| Power requirement | 5 V ± 5 % supplied by host PC (no external supply) |
| Physical dimensions | 135.7 mm × 121 mm × 21.6 mm |
| Weight | 0.11 kg |
| Operating temperature range | 0 °C ~ 50 °C |
| Operating humidity range | 10 % ~ 90 % RH (10 °C‑30 °C) |
It can control up to 14 GPIB instruments.
The card draws 5 V ± 5 % from the host computer and does not need an external power supply.
It is compatible with NI VISA and Keysight VISA.
The card measures 135.7 mm × 121 mm × 21.6 mm.
