The FlexLink Spiral Elevator Compact X85 is a high‑throughput, space‑saving vertical transport solution with detailed specifications and ordering information.
The FlexLink Spiral Elevator Compact X85 provides a compact, high‑throughput solution for vertical product transport without the need for additional controls. Its spiral‑shaped track saves floor space and can handle parcels, totes, and packed items such as shrink‑wrapped bottle packs or cartons.
Technical specifications include inclination per winding, speed ranges, load capacity, chain dimensions, and configurable lower and top heights. Ordering is performed via FlexLink’s online configurator, and standard accessories such as guide‑rail brackets and plastic guide rails are listed separately.
| Center diameter | 1000 mm |
|---|---|
| Lower height options | 600 mm, 700 mm, 800 mm, 900 mm, 1000 mm (adjustable ±50 mm) |
The standard Spiral Elevator can carry up to 10 kg per meter of conveyor length.
The standard model allows 3 to 8 windings, while the Fast‑track version allows 3 to 4 windings.
The Compact X85 can operate at 10, 20, 30, 40, or 50 meters per minute.
