The Feiyu Tech V1.2 3‑axis smartphone stabilizer user manual provides setup, balancing, operation modes, app connection, and firmware upgrade instructions.
This manual introduces the Feiyu Tech V1.2 three‑axis smartphone stabilizer, its components, charging method, and how to install a phone. It explains the initial setup steps, battery charging via Micro USB (5 V/2 A), and the required phone width range (57‑84 mm).
The guide covers balancing adjustments, power on/off procedures, multiple operation modes (heading follow, lock, auto‑rotate), and how to use the Feiyu ON app for firmware upgrades and additional features. Technical specifications such as weight, load capacity, battery life, and extension range are also listed. This manual is written in Chinese.
| Net weight (without phone) | 428 g |
|---|---|
| Maximum handle extension | 0–183 mm |
| Charging output | 5 V / 2 A |
| Supported phone weight | up to 210 g |
| Battery life (normal mode) | 10 hours |
Connect a USB data cable to the Micro‑USB port; the indicator light is red while charging and turns solid green when fully charged.
Long‑press the function key: a green light and beep indicate power‑on; a red flashing light and beep indicate power‑off.
Adjust the horizontal arm left or right until the phone is level; the stabilizer will indicate the optimal balance position.
