The Feiyu Tech G6 Plus handheld 3‑axis camera stabilizer user manual provides setup, balance adjustment, operation and parameter details.
This manual introduces the Feiyu Tech G6 Plus handheld 3‑axis camera stabilizer, covering an overview of its components, battery installation, and basic handling. It explains how to power the device, install a camera or phone, and connect to the Feiyu ON app.
Detailed sections guide users through balance adjustment for yaw, roll and pitch axes, basic and advanced operation modes, firmware upgrades, and parameter settings such as follow rates and angle ranges. Safety tips and initialization procedures are also included. This manual is written in Chinese.
| Phone clamp load capacity | 800 g |
|---|---|
| Net weight (without battery, camera) | 663 g |
| Battery type | 26650 Li‑ion 5000 mAh |
| Theoretical endurance | 9 hours |
| Yaw follow rate | 3°/s ~ 150°/s |
| Pitch follow rate | 2°/s ~ 75°/s |
| Pitch angle range | 260° |
| Roll angle range | 320° |
| Yaw angle range | 360° |
Press and hold the function key until the display shows a prompt and you hear a tone, then release.
Refer to the “Camera Connection” section (page 13) for detailed steps on linking the camera via the Micro USB port or Bluetooth.
Use the Micro USB port to connect the stabilizer to a computer and follow the firmware upgrade instructions in the manual.
