Installation guide for the Fagor Automation CNC 8070 covering software setup, machine parameters, PLC programming, safety and warranty.
This manual provides step‑by‑step instructions for installing the CNC 8070 system. It details software installation, required safety checks, hardware expansion limits, and warranty conditions. The safety section explains the required safety elements such as feedback alarms, software limits and error monitoring, and warns that disabling them voids warranty.
The guide also describes machine parameters, PLC architecture, tool‑magazine management, and the extensive list of CNC variables. Additional chapters cover PLC programming, CNC‑PLC communication, input/output logic, and configuration of axes, spindles, and high‑speed cutting modes. Technical specifications and optional software features are listed in the product overview.
| Operating system | Windows XP |
|---|---|
| Number of axes | 3 to 7 (or 3 to 28) |
| Number of spindles | 1 to 4 |
| Number of tool magazines | 1 to 4 |
| Digital inputs per module | 8, 16 or 32 |
| Analog inputs per module | 4, 4 or 8 |
Fagor Automation is not responsible for personal injury or damage, and the CNC will no longer be under warranty.
The manual applies to software version V04.1 X (reference 1107).
