The ENDURA ELITE 136Wh Li‑ion V‑Mount battery offers dual cartridges, IATA approval, Digi‑View LED display, and built‑in protection for HD camera use.
The ENDURA ELITE is a high‑capacity Li‑ion V‑Mount battery designed for HD cameras. It features two interchangeable PC‑14 power cartridges, IATA approval for unrestricted carry‑on, a Digi‑View LED capacity display, and a built‑in BMS for monitoring battery health.
Technical specifications include a 14.8 V, 9.2 Ah, 136 Wh capacity, 16.8 V max output, and protective circuitry against over‑charge, over‑discharge, over‑current and temperature extremes. The battery measures 3.94 × 6.69 × 2.76 inches and weighs about 2.76 lb.
| Battery Capacity | 14.8V, 9.2Ah, 136Wh |
|---|---|
| Max Output Voltage | 16.8V DC |
| Nominal Voltage | 14.8V DC |
| End Voltage | 12V (factory setting) |
| Battery Protection | Over charge, over discharge, over current, temperature protection |
| Charging Temperature Range | 32°F – 104°F (recommended 50°F – 86°F) |
| Discharge Temperature Range | -4°F – 122°F (recommended 50°F – 104°F) |
| Storage Temperature Range | -4°F – 140°F (recommended 32°F – 68°F) |
| Dimensions | 3.94(W) x 6.69(H) x 2.76(D) inches |
| Weight | 2.76 lbs (approx.) |
Yes, it is IATA approved for unrestricted carry‑on airline carriage.
Five LEDs on the side provide ten settings that show capacity in 10% increments using full or flashing combinations.
The battery can be charged between 32°F and 104°F, with a recommended range of 50°F to 86°F.
The ELITE contains two identical PC‑14 power cartridges housed inside its outer casing.
