The Elektron Model:Cycles user manual provides safety instructions, setup, operation, and technical specifications for the FM‑based groovebox.
This manual explains how to install, power, and safely operate the Elektron Model:Cycles groovebox. It includes safety warnings, FCC and EU compliance statements, and guidance on handling the unit and its accessories.
The document details the panel layout, controls, quick‑start procedures, sequencer functions, preset management, MIDI implementation, and technical specifications such as power consumption, audio output levels, dimensions, and recommended power supply.
| Main outputs level | +10 dBu |
|---|---|
| Headphones output level | +6 dBu |
| Unit power consumption | 2–4 W depending on LED/LCD brightness |
| Recommended power supply | PSU-4/b, 5 V DC, 1.2 A |
| Dimensions | W 270 × D 180 × H 39 mm (10.7" × 7.1" × 1.6") |
| Weight | approximately 0.8 kg (1.8 lbs) |
Use the recommended PSU‑4/b, 5 V DC, 1.2 A power supply.
The unit consumes between 2 and 4 W, depending on LED/LCD brightness.
