EdgeLight LC-CON-RGB-12~24V-72~144W RGB controller user manual with specifications, control methods, mode list, and safety precautions.
The EdgeLight LC-CON-RGB-12~24V-72~144W is an RGB controller designed for multi‑color LED conversion lamps, suitable for point LEDs, strips, wall washers, and other lighting fixtures. It features an infrared remote, multiple voltage options, and a variety of lighting effects such as hopping, gradual, and strobe.
The manual provides technical parameters, remote control operation, a full list of 24 lighting modes, wiring instructions, and safety precautions. It also details the supported voltage ranges, output current, remote distance, and connection modes (common anode or cathode). This manual is written in Chinese.
| Working Voltage | DC5V, DC12V, DC24V |
|---|---|
| Working Temperature | -20°C to +60°C |
| Max Total Output Current | 2A*3 |
| Remote Distance | 8 m |
| Size | 114 mm × 64 mm × 25 mm |
| Connecting Mode | Common anode, common cathode |
Press the “ON” button; the controller will start and automatically run the last mode before it was shut down.
The remote control works up to 8 meters away.
It supports DC5 V, DC12 V, or DC24 V input.
