Key facts
- Manuals
- 8
- Languages
- ZH
- Last added
- 2026-09-30
Featured EdgeLight manuals
EdgeLight LC-CON-RGB-12~24V-72~144W RGB Controller User Manual
The EdgeLight LC-CON-RGB-12~24V-72~144W is an RGB controller designed for multi‑color LED conversion lamps, suitable for point LEDs, strips, wall washers, and other lighting fixtures. It features an infrared remote, multiple voltage options, and a variety of lighting effects such as hopping, gradual, and strobe.
The manual provides technical parameters, remote control operation, a full list of 24 lighting modes, wiring instructions, and safety precautions. It also details the supported voltage ranges, output current, remote distance, and connection modes (common anode or cathode). This manual is written in Chinese.
Covers: Product Specifications · Technical Parameters · Control Method · Function Mode List · Precautions · Wiring Diagram
EdgeLight ALS-12V-1W4-480 LED Strip Specification Sheet
The EdgeLight ALS-12V-1W4-480 is a surface‑mount SMD LED strip on an aluminum substrate, intended for indoor use. The document provides a physical drawing, part numbers, and key LED characteristics such as wavelength and color temperature.
Technical requirements include operating temperature, storage limits, voltage, current, power consumption, luminous flux and illuminance, together with safety instructions for installation and use. This manual is written in Chinese.
Covers: Description · Physical Dimensions · LED Parameters · Technical Requirements · Usage Instructions · Specifications
EdgeLight AF42 User Manual
This manual explains how to safely operate and install the EdgeLight AF42 LED lighting panel. It includes warnings about water exposure, electrical safety, and the importance of reading the entire guide before use.
Key sections cover safety rules, wall‑mount installation, canvas replacement, power requirements (AC100‑240V), and a list of accessories. Technical data such as supported canvas sizes and a service life of over 50,000 hours are also provided. This manual is written in Chinese.
Covers: Safety Guidelines · Installation · Canvas Replacement · Specifications · Accessories
EdgeLight AF40 User Manual
This manual explains how to install, operate, and maintain the EdgeLight AF40 LED display. It includes safety warnings such as avoiding water exposure, not opening the back panel, and using the correct voltage. The safety section also advises keeping the manual for future reference.
The document lists physical dimensions for various frame sizes, mounting procedures for wall installation, and required accessories such as an AC100‑240V power supply. It also provides the LED lifespan and handling precautions during transport and cleaning. This manual is written in Chinese.
Covers: Safety Guidelines · Dimensions · Installation · Wall Mounting · Accessories
Latest EdgeLight manuals
EdgeLight LC-CON-RGB-12~24V-72~144W RGB Controller User Manual
User Manual 3 pages · 2.2 MB · ZHEdgeLight LC-CON-RGB-12~24V-72~144W RGB controller user manual with specifications, control methods, mode list, and safety precautions.
EdgeLight ALS-12V-1W4-480 LED Strip Specification Sheet
Product Leaflet 3 pages · 567 KB · ZHSpecification sheet for EdgeLight ALS-12V-1W4-480 indoor LED strip with dimensions, LED parameters and technical requirements.
EdgeLight CF3-A3/A4-X Manual
EdgeLight AF20 Manual
EdgeLight AF10 Manual
EdgeLight AF16 Manual
EdgeLight AF42 User Manual
User Manual 8 pages · 469 KB · ZHThe EdgeLight AF42 User Manual provides safety guidelines, installation steps, and operating instructions for the AF42 LED lighting panel.
EdgeLight AF40 User Manual
User Manual 6 pages · 322 KB · ZHThe EdgeLight AF40 user manual provides installation, safety, operation, and maintenance instructions for the LED display product.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in EdgeLight manuals
How do you turn the controller on?
Press the “ON” button; the controller will start and automatically run the last mode before it was shut down.
From: EdgeLight LC-CON-RGB-12~24V-72~144W RGB Controller User Manual
What is the remote control range?
The remote control works up to 8 meters away.
From: EdgeLight LC-CON-RGB-12~24V-72~144W RGB Controller User Manual
Can the LED strip be used outdoors?
No, the product is limited to indoor use only.
From: EdgeLight ALS-12V-1W4-480 LED Strip Specification Sheet
Is the EdgeLight AF42 waterproof?
No, the product is not waterproof and should not be placed in wet or damp environments.
Can I repair the device myself?
Do not attempt self‑repair; contact EdgeLight or a qualified service technician for any repairs.
Can the EdgeLight AF40 be used in wet environments?
No, the product is not waterproof and should not be placed near water, splashes, rain, or high humidity.
