Step‑by‑step installation guide for Bowers & Wilkins CWM6 Series wall‑mount speakers, covering wall aperture dimensions, wiring, positioning and specifications.
This manual provides detailed instructions for installing the Bowers & Wilkins CWM6 Series wall‑mount speakers in stud or sheetrock walls. It includes a list of carton contents, required wall aperture dimensions for each model, and safety notes such as keeping magnetically sensitive items at a safe distance.
The guide also covers positioning recommendations for various audio setups, cable routing and connection procedures, frame and baffle installation, painting tips, and the use of the high‑frequency level switch. Compliance information and warranty details are provided at the end of the document.
| CWM652 Aperture Height | 228mm (9 in) |
|---|---|
| CWM663 Aperture Height | 279mm (11 in) |
| CWM664 Aperture Height | 279mm (11 in) |
| Required clear depth behind sheetrock | 90mm (3.55 in) |
The CWM652 requires an aperture height of 228 mm (9 in) and an aperture width of 153 mm (6 in).
Use high‑quality, low‑resistance speaker cable, especially if the cable run exceeds 5 m.
The CWM663 model has six QuickDogs™ (spring clamps).
