Reference guide of hydraulic valve schematic symbols for Bosch Rexroth, covering many valve models and their functions.
This document provides a comprehensive collection of hydraulic schematic symbols used for Bosch Rexroth valves. It includes symbols for directional control valves, proportional valves, and other hydraulic components, along with brief descriptions of their operation.
The guide also mentions how to access the symbol library, offers technical data such as pressure and flow ratings for specific models, and points to additional training resources and product catalogs.
| Working pressure (4WE10 directional valve) | 32 MPa |
|---|---|
| Standard flow (4WE10 hydraulic valve) | 1201 m³/h |
| Maximum pressure rating (V040 valve) | 10 6 psi |
The working pressure of the 4WE10 directional valve is 32 MPa.
Click on the chart image to download a larger PDF format.
