The manual explains how to power, connect video/audio, configure the Blackmagic Web Presenter and use it with streaming software.
This guide walks you through the initial setup of the Blackmagic Web Presenter, including power connection, video and audio inputs, and USB connection to a computer. It also covers how to select the device as a webcam in various applications.
Further sections describe using the optional Teranex Mini Smart Panel, adjusting video and audio settings, and troubleshooting, with regulatory and warranty information at the end.
| Video input support | 12G‑SDI and HDMI, auto‑switches between SD, HD and Ultra HD up to 2160p60 |
|---|---|
| USB output resolution | Down‑converts to 720p for USB webcam output |
| Frame‑rate options | 20, 15, 10 or 5 fps selectable |
| USB interface | USB webcam source recognized by computer |
| Power connection | Standard IEC power cable |
Use a standard IEC power cable and plug it into the power input on the rear panel of the unit.
It accepts SD, HD and Ultra HD signals up to 2160p60 via SDI or HDMI and down‑converts them to 720p for the USB webcam output.
