This manual provides operation, installation, maintenance, and safety instructions for the BK Precision Model 2831D True RMS Digital Multimeter.
The BK Precision Model 2831D is a portable, bench-type True RMS digital multimeter featuring a 4 ½ digit LED display. It supports AC/DC voltage measurements up to 1200V DC and 750V AC, as well as current measurements up to 20A, resistance up to 20MΩ, frequency up to 200kHz, diode testing, and audible continuity tests. The device includes overload protection on all ranges.
| Display Type | 4 1/2 digit (LED) |
|---|---|
| DC Voltage Accuracy | ±(0.05% + 5d) |
| AC/DC Voltage Range | Up to DC 1200V, AC 750V |
| AC/DC Current Range | Up to 20A |
| Resistance Range | Up to 20MΩ |
| Frequency Range | Up to 200KHz |
| Dimensions | 9.4 x 3.5 x 10.6" (240 x 90 x 270mm) |
| Weight | 4.6lb (2.1 kg.) |
Allow a pre-heating period of as long as some 30 minutes after turning off power.
The instrument should be used between 10 °C and 35 °C for proper operation.
It requires a triple line power cord with protective earth contact (PE-contact).
