This service manual provides detailed disassembly, assembly, troubleshooting and maintenance procedures for Bendix aircraft magnetos.
The manual covers general description of Bendix magnetos, including the relationship between magneto type numbers and their configurations. It lists common series such as S1200, S4LN‑xxx, S4RN‑xxx, S6LN‑xxx, S20, S200 and D‑3000, and provides part‑number guidance for ordering replacement kits.
Detailed overhaul instructions are included, covering inspection, cleaning, part replacement, and the required maintenance intervals for four‑, five‑ and six‑cylinder magnetos. Safety precautions, service bulletins and FAA‑approved testing procedures are also documented to ensure reliable operation of aircraft ignition systems.
| Cylinder count | four, five, six |
|---|
When ordering, specify the magneto by its part number and indicate if it is a Red Label Magnetos – Factory New.
The Bendix S1200 series is the largest and heaviest magneto.
