The manual provides safety guidelines, system features, wiring diagrams, and operation instructions for the 3‑axis motion control system.
This document introduces the 3‑axis motion control system developed by Beijing Beijixingchen Technology. It covers safety precautions, system composition, technical specifications, controller panel layout, and wiring connections. The system uses a high‑performance 32‑bit CPU, an LCD display, and supports stepper or servo motors.
The manual also explains how to operate the system in manual and automatic modes, manage programs, configure PLC mixed‑programming, switch languages, and use the teaching function. Installation and wiring recommendations are provided to ensure reliable performance in various environments. This manual is written in Chinese.
| Operating Temperature | 0‑40 °C |
|---|---|
| Relative Humidity | 0‑85 % |
| LCD Resolution | 192 × 64 pixels |
| Isolated I/O Channels | 18 inputs, 8 outputs (24 V, 500 mA per channel) |
| Minimum Data Unit | 0.001 mm |
| Maximum Data Size | ±99 999.999 mm |
| Maximum Speed | 9 000 mm/min |
| Maximum Pulse Output Frequency | 150 kHz |
| Controlled Axes | 1‑4 axes (X, Y, Z, C) |
| Physical Dimensions | 174 × 94 × 45 mm |
| Panel Opening Size | 162 × 84 mm |
The system is designed to operate between 0 °C and 40 °C.
It provides 18 isolated 24 V inputs and 8 isolated 24 V outputs, each rated at 500 mA.
Go to Parameter Settings → System Parameters → Control Parameters → Language and select English, then confirm and save.
The warranty lasts for twelve months from the date of shipment.
