ADLEE POWERTRONIC SD2/MA Series Servo Motor and Drive Specifications Datasheet

Technical specifications for ADLEE POWERTRONIC SD2 and MA series servo motors, including electrical parameters, mechanical dimensions, and operational…

ADLEE POWERTRONIC SD2/MA Series Servo Motor and Drive Specifications Datasheet - cover page
Brand
Adlee Powertronic
Category
Motor
Document type
Datasheet
Language
Chinese
Pages
83
File format
PDF
File size
1009 KB
Published
16 October, 2026
Updated
16 October, 2026
MD5 checksum
BFB5A6D45BE157C44A43F0378EAC61C2
PDF
ADLEE POWERTRONIC SD2/MA Series Servo Motor and Drive Specifications Datasheet PDF

About this manual

This document provides detailed technical data for the ADLEE POWERTRONIC SD2 and MA series of servo motors. It covers various motor models ranging from 120W to 2.2KW output power, detailing their rated speeds, torque, voltage requirements, and insulation classes.

The datasheet includes comprehensive mechanical dimension drawings for different shaft sizes (No.3 through No.8) and lists specific parameters such as moment of inertia, acceleration time, and encoder resolution. It also outlines the drive specifications compatible with these motors. This manual is written in Chinese.

What's inside

  • SD2 Series Motor Specifications
  • MA Series Motor Specifications
  • Mechanical Dimensions
  • Electrical Parameters
  • Drive Compatibility
  • Encoder Resolution
  • Insulation Class
  • Operating Temperature

Specifications

Output Power Range (MA Series)120W to 2.2KW
Encoder Resolution128 PPR
Insulation ClassF

Frequently asked questions

What is the maximum rated speed for the MA-370M servo motor?

The maximum rated speed is 3000 RPM.

Download PDF (1009 KB)
