This document introduces the 2-phase stepping system STEPPING SYSTEMS Ve V r.2 1, which includes overseas specifications of stepping drivers and stepping motors, with features such as low vibration mode, DC input, small size, and light weight.
This manual covers the SANMOTION stepping system, including the F series driver, ION H series motor, and SH series motor. It provides wiring diagrams, connector details, safety information, and performance data for the phase stepping system.
The document also lists electrical parameters, pulse frequency limits, and recommended connection methods, helping users set up and maintain the system safely and efficiently.
| Operating Voltage | DC24V +10% |
|---|---|
| Pulse Frequency | up to 250k pulse/s |
| Maximum Frequency | 2000 Hz |
The system operates at DC24V with a tolerance of plus or minus 10%.
The driver can generate pulses up to 250 k pulse/s.
The system supports signal frequencies up to 2000 Hz.
