This document is the user manual for the EM-LPC1300 development board, which provides an overview, quick start guide, detailed description, and introduction to software resources.
This manual introduces the EM-LPC1300 development board, based on the NXP LPC1343FBD 48‑bit ARM Cortex‑M3 microcontroller. It details the board’s hardware resources, such as USB, UART, ADC, timers, and power‑management unit, and lists the supplied software examples for rapid prototyping.
The document also covers quick‑start procedures, how to connect peripherals, compile and download firmware using the ULINK2 debugger, and provides troubleshooting and technical support information for developers. This manual is written in Chinese.
| Core processor | LPC1343FBD 48 (ARM Cortex‑M3) |
|---|---|
| CPU frequency | 72 MHz |
| Operating voltage | 2.0 V – 3.6 V |
| Operating temperature range | -65 °C to +150 °C |
| USB interface | Full‑speed USB 2.0 (Mini‑AB connector) |
| UART | UART with RS‑485/EIA‑485 support |
| ADC channels | 8‑channel 10‑bit ADC |
| Timers | 2 × 16‑bit timers, 2 × 32‑bit timers |
| LEDs | 8 user LEDs + 1 power LED |
| Power source | USB powered |
The kit contains one EM‑LPC1300 board, a cross‑serial cable, a USB cable, and a product CD.
Press the RESET button on the board to return to the function‑selection screen.
It uses the NXP LPC1343FBD 48 microcontroller with an ARM Cortex‑M3 core.
