This manual covers safety information, installation precautions, and operating procedures for the iTrust UPS series. It explains proper grounding, handling of high‑voltage components, and environmental restrictions such as temperature and humidity limits.
The document also lists technical specifications, RS‑232 communication details, and optional accessories such as SNMP modules, battery packs (38 Ah, 65 Ah, 100 Ah), chargers, and surge‑protect devices. Appendices provide product specifications and a parts list for each model. This manual is written in Chinese.
| Capacity | 1 kVA, 2 kVA, 3 kVA |
|---|---|
| Operating temperature range | 0 °C to +40 °C |
| Storage temperature (without battery) | -40 °C to +70 °C |
| Storage temperature (with battery) | -20 °C to +55 °C |
| Weight (kg) – 1 kVA model | 14 kg |
| Weight (kg) – 2 kVA model | 40 kg |
Battery replacement must be performed by authorized service personnel after the UPS is completely powered down and disconnected.
The UPS operates safely between 0 °C and +40 °C.
