This document describes how to install, configure, and use PS Series storage arrays to create an economical, easy-to-use, self-managed iSCSI storage area network (SAN).
This guide explains how to install the hardware of Dell PS5000 and PS5500 storage arrays, connect power and network cables, and prepare the units for use. It also covers the software configuration steps required to initialize the arrays, create iSCSI groups, and set up RAID policies.
After hardware installation, the manual details the use of the PS Series Group Manager GUI and CLI tools for creating volumes, assigning access controls, and managing advanced group tasks. Environmental requirements, safety precautions, and technical specifications are provided in dedicated sections. This manual is written in Chinese.
| Maximum operating temperature | 41 to 95 °F (5 to 35 °C) |
|---|---|
| Input voltage | 100 V to 240 V AC (auto‑sensing) |
| Maximum system input power (PS5000) | 530 VA |
| Maximum system input power (PS5500) | 1400 VA |
| Weight (full load, PS5000) | 77.6 lb (35 kg) |
| Power supply output (PS5500) | 440 W DC per power supply |
The PS5000 accepts an input voltage of 100 V to 240 V AC with auto‑sensing.
The PS5500 can draw up to 1400 VA of power.
Each power supply in the PS5500 delivers 440 W of DC output.
