SINOVT 6N3 6V6 Push Pull Kit is a simple and easy to assemble electronic tube amplifier kit, equipped with Rafael high-quality 10K push-pull output transformer, ensuring the highest quality music reproduction.
The SINOVT 6N3/6V6 push‑pull kit is a tube‑amplifier assembly package that includes a 6N3 pre‑amplifier tube, a 6V6 power tube, high‑quality output transformer and all necessary components for building a high‑fidelity audio amplifier. The manual guides users through receiving inspection, chassis installation, component wiring, and final system debugging.
The document is organized into sections covering model introduction, receiving inspection, detailed assembly steps (chassis, component soldering, transformer wiring), circuit diagrams, assembly drawings, full‑system testing, common fault troubleshooting, and optional upgrades such as tube and capacitor replacements. Service contact information is provided at the end. This manual is written in Chinese.
| Capacitor C16 rating | 47 µF, 400 V |
|---|---|
| Resistor R47 rating | 150 kΩ, 2 W |
