This document introduces the features and characteristics of GSK980TB lathe CNC system, including programming instructions, electrical design knowledge, usage precautions, installation and debugging steps and methods, and other necessary knowledge for using this system.
This manual describes the functions, programming methods, electrical design, installation steps and safety precautions for the GSK980TB lathe CNC system. It is intended for qualified personnel who operate, maintain or service the machine.
The document includes a detailed table of contents covering system overview, programming basics, operation panel description, system connections, machine tuning, and extensive appendices with specifications, diagnostic tables and installation drawings. This manual is written in Chinese.
| Control axes | 2 (X, Z) |
|---|---|
| Minimum setting unit | 0.001 mm |
| Minimum movement unit | 0.001 mm |
| Maximum feed rate (rapid) | 6 m/min (standard) |
| Maximum spindle speed | 9999 rpm |
| I/O interface | RS232C |
The system controls two axes, X and Z.
The smallest movement increment is 0.001 mm.
The controller provides an emergency stop (急停) that immediately halts operation.
The spindle can run up to 9 999 rpm.
