Holtek EW-VMF User Manual

This document is a user manual for the EW-VMF burner, which introduces the features and functions of the burner, as well as the supported burning boards and simulation lists.

Holtek EW-VMF User Manual - cover page
Brand
EW
Category
Other software
Document type
User Manual
Language
English
Pages
16
File format
PDF
File size
680 KB
Published
03 November, 2011
Updated
29 September, 2023
MD5 checksum
82E0ABAF0E3D521BA7CABB52F66F3AA4
PDF
Holtek EW-VMF User Manual PDF

About this manual

The EW-VMF User Manual describes the HT-VMF Writer software, a tool for programming and verifying flash memory on Holtek EV boards. It includes a setup wizard, installation steps, and detailed instructions for programming both music and voice ROMs.

The guide also lists supported flash memory devices, required system resources, and provides tables of address ranges for programming. Users can follow the step‑by‑step process to erase, program, and verify firmware files using the software.

What's inside

  • Setup Wizard
  • Installation Requirements
  • Program ROM
  • Process Range Setting
  • File Management
  • Flash Memory Support
  • Verification Procedure

Specifications

Required Disk SpaceAt least 1.4 MB
Supported Flash MemoryMX29LV320D 32 Mbit (LOFP 80)

Frequently asked questions

How much free disk space is needed to install the HT‑VMF Writer?

At least 1.4 MB of free disk space is required.

What flash memory device is supported by the writer?

The writer supports the MX29LV320D 32 Mbit flash memory.

Download PDF (680 KB)
