The document is a safety manual for a product. It provides detailed information on safety warnings, symbol explanations, and important usage and maintenance instructions for the product.
This manual covers safety warnings, FCC compliance information, and battery disposal instructions for the Yamaha DME64N/DME24N digital mixing engine. It explains the risk of electric shock, the need for proper grounding, and the prohibition of user‑serviceable parts.
Installation details include wiring instructions for the mains plug, connector pin assignments, and specifications for Euroblock connectors. Technical data such as input/output characteristics, dimensions, and MIDI data format are also provided.
| Battery type | Lithium battery for memory backup |
|---|---|
| Euroblock connector (16‑pin) | 16P x 2 |
| Euroblock connector (8‑pin) | 8P x 4 |
| Euroblock connector for DME24N | 8P x 16 |
It contains a lithium battery used for memory backup.
The device complies with FCC Class B digital device requirements.
