XK3101 weighing display controller (enterprise model: Allto1-D high-end dual scale instrument) is a high-end dual scale weighing instrument independently designed, developed and produced by Shandong Setaq Instruments Co., Ltd. It is mainly used for vehicle scale and can simultaneously connect two scales (analog scale, digital scale or Hirs series multi-channel A/D digital junction box).
The SeTAQ XK3101 is a high‑end dual‑channel weight display controller designed for precise weighing applications. It supports various input types such as analog, digital, and Hirs series multi‑channel A/D converters.
The document covers system overview, functional description, interface connections (RS232, RS485, USB, Profibus), main screen operation, parameter configuration, data output formats, system diagnostics, and a troubleshooting guide with fault codes and solutions. This manual is written in Chinese.
