This document is a collection of hardware manuals and firmware manuals, which introduces the installation, maintenance, and technical data of the ACS800 series frequency converters. It also provides related application firmware manuals and custom programming application guides, as well as optional accessory manuals.
The manual is intended for engineers who design, install, commission, operate, and maintain the ACS800 du/dt filters. It covers safety requirements, selection guidelines, mechanical and electrical installation, wiring diagrams, grounding, and technical specifications.
Key sections include filter selection tables, installation planning, mechanical mounting, electrical connections, cooling requirements, and detailed dimension drawings for each model. The document also lists environmental conditions and provides example calculations for voltage spikes and du/dt values. This manual is written in Chinese.
| Maximum surface temperature | 150 °C |
|---|---|
| Cooling time before maintenance | 2 hours |
Only qualified electrical engineers may install, commission, and maintain the du/dt filter.
The filter’s surface temperature can exceed 150 °C.
It must cool for two hours before maintenance can be performed.
