The EEE series solid state relays feature DC control, AC zero-crossing conduction, and zero-crossing shutdown. They have smooth startup performance, low radiation interference to the power grid, and provide protection for appliances and solid state relays. They are suitable for controlling motors, heaters, incandescent lamps, etc.
The BESTMALL E series solid state relay guide provides detailed technical parameters, input and output control characteristics, and general specifications for the E series devices. It includes information on the relay’s low di/dt ratio, reduced electromagnetic interference, and protection benefits for inductive loads such as motors and heaters.
Installation recommendations are described, specifying a through‑hole PCB mounting style and the need for appropriate heatsinks for currents above 10 A. Thermal management guidelines state that the contact temperature between the SSR base plate and heatsink must not exceed 80 °C. This manual is written in Chinese.
| Mounting type | Through‑hole PCB |
|---|
The guide specifies a through‑hole PCB mounting style.
The contact surface temperature must not exceed 80 °C.
