D series solid state relay is DC input, DC output type, can realize DC level conversion, isolation and control, can be convenient to interface with computer and various digital circuits. It is widely used in industrial automation field for the control of various DC power execution organs, such as lighting equipment, small DC motors, DC power supplies, various electromagnetic devices and intelligent instruments, and can also be used as the driving stage of various high-power output devices. Easy to use, especially suitable for corrosive, humid and explosion-proof occasions.
The D0211-32C is a DC‑input, DC‑output solid‑state relay designed for level conversion, isolation and control. It can be interfaced directly with computers and digital circuits and is suited for harsh environments such as corrosive, humid or explosion‑prone locations.
Installation requires a straight‑insertion PCB mount, a heat‑sink for continuous operation at rated current, and derating when ambient temperature is high. When driving capacitive loads, surge current must be limited; for inductive loads, transient over‑voltage must be limited. This manual is written in Chinese.
| Rated output voltage | 110 Vdc |
|---|---|
| Rated output current | 2 A |
The rated output current is 2 A.
Install a heat sink, derate the device at high ambient temperatures, limit surge current for capacitive loads, and limit transient over‑voltage for inductive loads.
The relay is designed for straight‑insertion PCB mounting.
