The Hybertone FXS series gateway is a high‑performance broadband gateway that connects analog phones to VoIP networks or service providers. It supports H.323 and SIP protocols, offers line‑detection, echo cancellation and multiple voice codecs.
This manual provides an overview of the product, hardware and software features, packaging contents, physical layout, connection diagrams, configuration steps, phonebook management, tools such as firmware upgrade, and detailed dialing‑rule syntax. This manual is written in Chinese.
| Processor | ARM9E high‑speed processor |
|---|---|
| Ethernet ports | Two 10/100 Mbps Ethernet ports |
| Power supply | DC24 V / 500 mA transformer |
| Voice codecs | G.711 A‑Law/µ‑Law, G.729A, G.729AB, G.723.1, GSM |
| Operating system | Linux OS |
Press the small reset pinhole on the back of the device; the gateway will restart.
Enter the new password twice and click the “Change” button in the user or admin interface.
Do not power off the device while the upgrade is in progress, otherwise the device may be damaged.
