The ASUS VH203 20-inch wide-screen color LCD display features a 5ms response time / 1000:1 contrast ratio (dynamic contrast 10000:1 with ASCR) SPLENDID�image smart technology, and provides three-year full warranty and three-year home delivery service.
This manual covers the key specifications of the ASUS VH203 19‑inch TFT LCD monitor, including panel type, resolution, brightness, contrast ratio, and connectivity options. It also describes built‑in features such as OSD controls, anti‑glare coating, and VESA mounting.
The document lists the supplied accessories, warranty details, and compliance certifications. Users can refer to the quick‑install guide and safety information to set up the monitor correctly. This manual is written in Japanese.
| Panel type | TFT LCD |
|---|---|
| Screen size | 19.0" |
| Maximum resolution | 1280x1024 @60Hz |
| Pixel pitch | 0.294 mm |
| Brightness | 300 cd/m² (Typ.) |
| Contrast ratio | 1000:1 (Typ.) |
| Dynamic contrast ratio | 2000:1 with ASCR |
| Viewing angle | 170°/160° |
| Color depth | 16.7 million colors |
| Response time | 5 ms (Gt+T) |
| Refresh rate | 30‑82 kHz / 56‑76 Hz |
| Inputs | Digital 24‑Pin DVI‑D, Analog 15‑Pin D‑Sub |
| Built‑in speakers | 2 W × 2 (RMS) |
| OSD function | Available |
| VESA mount | 100 mm × 100 mm |
| Power consumption | Typical <42 W, Standby <2 W |
| Dimensions (W×H×D) | 413 mm × 405 mm × 210 mm |
| Weight | 4.3 kg |
The monitor has a 19.0‑inch display.
It uses a TFT LCD panel.
Yes, it has a VESA mount pattern of 100 mm × 100 mm.
