This manual covers safety precautions, pre‑installation checks, and detailed procedures for installing the CPU, memory modules, and expansion cards on the M2N‑MX motherboard. It also describes connector locations, jumper settings, and component handling to ensure reliable operation.
Later sections explain BIOS setup, including EZ Flash and AFUDOS utilities, power management options, and RAID configuration using the onboard RAID support. The document finishes with troubleshooting tips and warranty information. This manual is written in Chinese.
| PCI Express x1 slot | Present |
|---|---|
| PCI Express x16 slot | Present |
| SATA ports | 4 (SATA1‑SATA4) |
It provides four SATA ports labeled SATA1 through SATA4.
The manual mentions EZ Flash and AFUDOS as BIOS update utilities.
